Product Description:
Connector series: M12 to RJ45 Adapter
Gender: Female
Coding: A,D
Locking type: Fix screw
Mounting type: Right angle
Part No.: M12-A/D-4-F-RJ45-RA
Download:
M12-AD-4-F-RJ45-RA.pdf
General Information:
|
Coding |
A |
D |
|
Number of contacts |
8 |
4 |
|
Rated voltage |
30V |
250V |
|
Rated current |
2A |
4A |
| Connector locking system | Solder | |
|
Operating temperature |
-25℃ ~ +85℃ |
|
|
Degree of protection |
IP67/IP68 |
|
|
Mechanical operation |
>500 mating cycles |
|
|
Contact resistance |
≤10 MΩ |
|
|
Material of connector |
CuZn,TPU |
|
|
Contact plating |
AU (gold plating) |
|
| Standard | IEC | |
